ULN2802A Darlington Transistor Array from STMicroelectronics

The ULN2802A, manufactured by STMicroelectronics, is an advanced high-voltage, high-current Darlington transistor array. This integrated circuit is designed to interface between low-level logic circuitry and multiple peripheral power loads. The ULN2802A consists of eight NPN Darlington pairs that feature high-voltage outputs with common-cathode clamp diodes for switching inductive loads.

Each channel of the ULN2802A is rated at 500 mA and can withstand peak currents of 600 mA. The suppression diodes safeguard the device from inductive spikes, making this array ideal for driving a wide range of loads such as relays, solenoids, stepper motors, and other high-current or high-voltage devices in various applications, including automotive, industrial, and consumer electronics.

Key features of the ULN2802A include:

• Output Voltage: The array can handle output voltages up to 50V, making it suitable for many high-voltage applications.
• Output Current: Each of the eight channels can deliver up to 500 mA of continuous current, with the capability to handle peak currents of 600 mA.
• Input Compatibility: The inputs are compatible with popular logic types such as TTL and CMOS, ensuring easy integration with microcontrollers and other digital systems.
• Clamp Diodes: Built-in clamp diodes provide protection against inductive load transients, which is critical for driving inductive loads safely and reliably.
• High Current Gain: The Darlington pairs have a high current gain, which allows for the control of high-current outputs with minimal input current from the controlling device.

The ULN2802A is available in a standard 18-pin DIP (dual inline package) or SO (small outline) package, offering flexibility in design for PCB layouts. Its robustness and ease of use make it an excellent choice for designers who require a reliable solution for interfacing low-level logic signals to higher power loads.

STMicroelectronics' commitment to quality ensures that the ULN2802A meets the stringent requirements of the most demanding applications, providing a cost-effective and space-efficient solution for driving a variety of loads with ease and precision.
