Products specifications

Categories Integrated Circuits
Manufacturer STMicroelectronics
Packaging Reel - TR
Status Active
Switch Type General Purpose
Number of Outputs 1
Output Type N-Channel
Voltage - Load 5.5 V to 36 V
Supply Voltage - Operating Not Required
Current - Output (Max) 2.5A
Rds On (Typ) 60 mOhm
Input Type Non-Inverting
Features Auto Restart, Status Flag
Fault Protection Current Limiting (Fixed), Over Temperature, Over Voltage
Temperature Range - Operating -40°C to 150°C (TJ)
Case / Package 8-SO
Win Source Part Number 036427-VN751STR
Family Name VN751S
Introduction Date March 08, 2005
ECCN EAR99
Country of Origin China
Halogen Free Compliant
Estimated EOL Date 2026
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian VN751STR CAD Model

Description

STMicroelectronics VN751STR High-Side Driver

The VN751STR from STMicroelectronics is a cutting-edge, high-side driver that has been meticulously engineered to provide a robust and efficient solution for driving inductive, resistive, or capacitive loads with one side connected to ground. This component is part of ST's VIPower™ M0-3 family, which is renowned for its smart power solid-state relays integrated with advanced protection features.

Constructed with ST's proprietary VIPower technology, the VN751STR offers a load current limit of 2.5 A, making it an excellent choice for a wide range of automotive applications, including but not limited to driving bulbs, buzzers, and other car body loads. The device operates over a wide voltage range from 5.5V to 36V, providing flexibility in various operating conditions and ensuring compatibility with 12V automotive systems.

This high-side driver is equipped with an array of protection features that safeguard the chip and the load from electrical hazards. The built-in thermal shutdown with hysteresis, open-load detection, and current limitation protect the device from the harsh conditions typically found in automotive environments. Additionally, the VN751STR features an active VCC clamp for enhanced energy handling when the device is demagnetizing inductive loads.

The VN751STR comes in a compact and thermally efficient SO-8 package, which is suitable for space-constrained applications. The device includes a diagnostic feedback that indicates the status of the driver, whether it is open-load in the off-state, overtemperature, or overload conditions. This feedback can be interfaced with microcontrollers, allowing for sophisticated control and monitoring of the load status.

With its advanced design and comprehensive protective features, the VN751STR high-side driver is an ideal solution for designers seeking a reliable and high-performance component for their automotive applications. Its robustness, combined with diagnostic capabilities, ensures that it can meet the stringent requirements of modern automotive electronic systems.
