Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer STMicroelectronics
Packaging Tube
Status Obsolete
Switch Type General Purpose
Output Configuration High Side
Output Type N-Channel
Interface On/Off
Load Voltage (V) 5.5V ~ 36V
Supply Voltage Not Required
Current - Output (Maximum) 30A
Rds On 18mOhm (Maximum)
Input Type Non-Inverting
Features Auto Restart
Fault Protection Current Limiting (Fixed), Open Load Detect, Over Temperature, Over Voltage
Temperature Range - Operating -40°C ~ 150°C
Manufacturer Package P2PAK (4 Leads + Tab)
Supplier Device Package P2PAK
Family Part Number VN920
Manufacturer Pack Quantity 50
MSL Level 1 (Unlimited)
Win Source Part Number 1279556-VN920D-B5
Manufacturer Homepage www.st.com
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian VN920D-B5 CAD Model

Description

The VN920D-B5 is an advanced automotive-grade power switch, designed and manufactured by STMicroelectronics, a leader in the semiconductor industry. This high-side driver is specifically engineered to manage a wide range of automotive applications, providing a reliable and efficient solution for driving resistive, inductive, and capacitive loads.

Key Features

  • High-Side Switch: The VN920D-B5 operates as a high-side switch, making it suitable for connecting loads to the positive supply rail.
  • Current Limitation: It features an active current limitation to protect the device against overload conditions.
  • Thermal Shutdown: The thermal shutdown with auto-restart ensures the device operates within safe temperature limits.
  • Integrated Diagnostics: The inclusion of diagnostic functions allows for the detection of open load in the off-state and loss of ground or supply.
  • Overvoltage Clamp: An overvoltage clamp protects sensitive loads against transient voltage spikes.
  • Fast Demagnetization of Inductive Loads: The VN920D-B5 is capable of handling fast demagnetization of inductive loads, making it ideal for automotive environments.

Applications

The VN920D-B5 is versatile and can be used in a variety of automotive applications, including but not limited to:

  • Lamp driving
  • DC motor control in applications such as power windows and mirrors
  • Control of resistive and capacitive loads

Quality and Reliability

STMicroelectronics has a reputation for quality, and the VN920D-B5 is no exception. It is designed to meet the stringent requirements of the automotive industry, ensuring high reliability and performance under harsh conditions. The device is compliant with the ISO 26262 standard for functional safety in road vehicles, making it a trustworthy choice for safety-critical automotive systems.

Conclusion

In summary, the VN920D-B5 from STMicroelectronics is a robust, high-performance power switch that offers a combination of protection features, diagnostic capabilities, and compliance with automotive standards. Its ability to drive a wide range of loads with efficiency and reliability makes it an excellent choice for designers and engineers looking to enhance the performance and safety of automotive electrical systems.
