Products specifications

Categories Integrated Circuits
Manufacturer STMicroelectronics
Packaging Reel
Switch Type General Purpose
Number of Outputs 2
Output Configuration High Side
Output Type N-Channel
Interface On/Off
Load Voltage (V) 4V ~ 28V
Supply Voltage Not Required
Current - Output (Maximum) 21A
Rds On 50mOhm
Input Type Non-Inverting
Features Auto Restart, Status Flag
Fault Protection Current Limiting (Fixed), Open Load Detect, Over Temperature, Over Voltage, UVLO
Temperature Range - Operating -40°C ~ 150°C
Manufacturer Package 16-PowerLFSOP
Supplier Device Package PowerSSO-16
Manufacturer Pack Quantity 1
MSL Level 3 (168 Hours)
Win Source Part Number 1279607-VND7050AJTR
Manufacturer Homepage www.st.com
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Family Name VND7050AJ
Introduction Date May 19, 2015
ECCN EAR99
Country of Origin Morocco
Halogen Free Compliant
Estimated EOL Date 2034
Ultra Librarian 3D Model Ultra Librarian VND7050AJTR CAD Model

Description

Product Overview: VND7050AJTR by STMicroelectronics

The VND7050AJTR is a state-of-the-art automotive-grade Power MOSFET from STMicroelectronics, designed to deliver high-efficiency power management and switching capabilities. This device is part of ST's VIPower M0-7 series and is specifically engineered to meet the rigorous standards of the automotive industry, offering outstanding performance in a wide range of applications.

Key Features

  • High-Side Switch: The VND7050AJTR operates as a high-side switch, allowing for direct control of the power supply to various automotive loads.
  • Current Rating: It can handle a continuous current of up to 30A, making it suitable for heavy-duty operations.
  • On-State Resistance: The device boasts a low on-state resistance of 13 mΩ typical at 25°C, ensuring minimal power loss and improved efficiency.
  • Protection Features: Includes overcurrent, overtemperature, load dump voltage surge, and active clamp protection, safeguarding the device and connected components from potential damage.
  • Diagnostic Functions: Equipped with diagnostic features that provide feedback on the status of the device and the load, facilitating maintenance and troubleshooting.

Applications

The VND7050AJTR is ideal for a variety of automotive applications, including but not limited to:

  • Automotive lighting systems
  • Engine control units
  • Body control modules
  • Intelligent battery power distribution

Package and Quality

The device comes in a compact and robust PowerSSO-12 package, ensuring a minimal footprint on the PCB while providing excellent thermal performance. The VND7050AJTR is AEC-Q100 qualified, reflecting its reliability and suitability for the harsh conditions encountered in automotive environments.

Environmental Compliance

STMicroelectronics is committed to environmental sustainability. The VND7050AJTR is compliant with RoHS and designed to meet the current environmental standards, reducing the environmental impact of automotive electronics.
