Products specifications

Categories Integrated Circuits
Manufacturer STMicroelectronics
Packaging Reel
Switch Type General Purpose
Number of Outputs 2
Output Configuration High Side
Output Type N-Channel
Interface On/Off
Load Voltage (V) 4V ~ 28V
Supply Voltage Not Required
Current - Output (Maximum) 8A
Rds On 140mOhm
Input Type Non-Inverting
Features Auto Restart, Status Flag
Fault Protection Current Limiting (Fixed), Open Load Detect, Over Temperature, Over Voltage, UVLO
Temperature Range - Operating -40°C ~ 150°C
Manufacturer Package 16-PowerLFSOP
Supplier Device Package PowerSSO-16
Manufacturer Pack Quantity 1
MSL Level 3 (168 Hours)
Win Source Part Number 1279609-VND7140AJTR
Manufacturer Homepage www.st.com
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Family Name VND7140AJ
ECCN EAR99
Country of Origin China, Morocco
Halogen Free Compliant
Estimated EOL Date 2030
Ultra Librarian 3D Model Ultra Librarian VND7140AJTR CAD Model

Description

The VND7140AJTR is a sophisticated automotive-grade power load driver from STMicroelectronics, designed to deliver outstanding performance and reliability for a wide array of vehicular applications. This device is part of the VIPower M0-7 series and is engineered to handle high-power loads with efficiency and precision.

Key Features

  • High-Side Driver: The VND7140AJTR operates as a high-side driver, allowing for direct control of power loads. This configuration simplifies the driving of inductive, resistive, or capacitive loads with enhanced protection features.
  • Current Limitation: It offers a built-in current limitation to safeguard the system from overcurrent conditions, thus ensuring the longevity and safety of both the load and the driver itself.
  • Thermal Shutdown: The thermal shutdown feature with auto-restart ensures that the device operates within safe temperature limits, preventing damage from overheating.
  • Overvoltage Clamp: An integrated overvoltage clamp protects the device and the load against transient conditions, enhancing the robustness of the application.
  • Load Dump Protection: Designed to withstand load dump pulses, the VND7140AJTR is ideal for the harsh electrical environment of automotive applications.
  • Status Feedback: The device provides real-time diagnostic feedback that can be used to monitor the status of the load, enhancing system control and reliability.

Applications

The VND7140AJTR's robust design makes it suitable for a variety of automotive applications including, but not limited to:

  • Lamp driving
  • Heater control
  • DC motor control in applications such as power windows, wipers, and HVAC blowers

Quality and Reliability

STMicroelectronics ensures that the VND7140AJTR meets the stringent requirements of automotive standards. The device is AEC-Q100 qualified, meaning it has passed rigorous testing for automotive electronic components. It is also housed in a compact and robust PowerSSO-16 package, which aids in thermal dissipation and space-saving on the PCB.

Whether you are an automotive system designer or an electronics enthusiast looking to integrate reliable power control into your project, the VND7140AJTR from STMicroelectronics offers a blend of performance, protection, and diagnostic capabilities that make it an excellent choice for driving high-power loads in automotive environments.
