Products specifications

Categories Integrated Circuits
Manufacturer STMicroelectronics
Packaging Reel - TR
Status Active
Switch Type General Purpose
Number of Outputs 1
Output Type N-Channel
Voltage - Load 36V (Max)
Supply Voltage - Operating Not Required
Current - Output (Max) 1.7A
Rds On (Typ) 250 mOhm (Max)
Input Type Non-Inverting
Fault Protection Current Limiting (Fixed), Over Temperature, Over Voltage
Temperature Range - Operating -40°C to 150°C (TJ)
Case / Package SOT-223
Win Source Part Number 036452-VNN1NV04PTR-E
Family Name VNN1NV04P
Introduction Date May 16, 2009
ECCN EAR99
Country of Origin United States of America
Halogen Free Compliant
Estimated EOL Date 2026
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian VNN1NV04PTR-E CAD Model

Description

Product Overview: VNN1NV04PTR-E by STMicroelectronics

The VNN1NV04PTR-E is a cutting-edge, high-performance power MOSFET produced by STMicroelectronics, a global leader in semiconductor solutions. This device is part of STMicroelectronics' OMNIFET II series, which is renowned for its robustness and efficiency in handling power management tasks.

Key Features

  • Low On-Resistance: The VNN1NV04PTR-E is designed with a low on-resistance, ensuring minimal power loss and improved efficiency in operation.
  • High Current Capability: This MOSFET can handle a high continuous current, making it suitable for demanding applications that require reliable power delivery.
  • Thermal Overload Protection: An integrated thermal shutdown feature protects the device from damage due to excessive heat, enhancing its reliability and lifespan.
  • Short Circuit Protection: The MOSFET includes short circuit protection, which safeguards the device and the system it's integrated into from potential damage caused by circuit malfunctions.
  • ESD Protection: Electrostatic discharge protection is built into the VNN1NV04PTR-E, ensuring that the device is less susceptible to damage from unexpected electrical surges.

Applications

The VNN1NV04PTR-E is ideally suited for a variety of applications where efficient power management and protection are critical. These applications include:

  • Automotive systems
  • Power management circuits
  • Motor control units
  • LED lighting systems
  • Industrial automation

Product Specifications

The VNN1NV04PTR-E operates within a voltage range that is optimal for many power-intensive applications. Its robust package ensures that it can withstand challenging environmental conditions, making it a reliable choice for both industrial and automotive applications.

Conclusion

STMicroelectronics' VNN1NV04PTR-E is a testament to the company's commitment to providing advanced power management solutions. With its combination of high performance, comprehensive protection features, and suitability for a wide range of applications, this MOSFET is an excellent choice for designers seeking a reliable and efficient power management component.
