The VNN3NV04PTR-E from STMicroelectronics is a robust, high-performance MOSFET designed to deliver efficient power management in a wide array of applications. This power MOSFET is a part of the OMNIFET II™ series, which is renowned for its fully autoprotected Power MOSFETs, ensuring reliability and performance.

Key Features

• Device Type: Power MOSFET
• Technology: OMNIFET II™
• Package: PowerSSO-12
• Drain-to-Source Voltage (Vds): 40V
• Current Rating: 30A
• Thermal Resistance: Low Rds(on)
• Protection Features: Overtemperature, Overcurrent, and Active Clamp

Applications

The VNN3NV04PTR-E is suitable for a diverse range of applications, including but not limited to:

• Automotive Load Control
• Intelligent Power Switches
• DC Motor Control
• Power Management Solutions

Protection and Reliability

STMicroelectronics has equipped the VNN3NV04PTR-E with advanced protection features that ensure the MOSFET operates safely under a variety of conditions. Its overtemperature shutdown with auto-restart and overcurrent protection guards the device and the system it powers. The inclusion of an active clamp circuit enhances the robustness of the device against harsh electrical transients.

Energy Efficiency

With its low on-state resistance (Rds(on)), the VNN3NV04PTR-E offers reduced conduction losses, which is essential for energy-efficient operation in power-intensive applications. This characteristic, combined with the device's ability to handle significant current loads, makes it an excellent choice for designs where power efficiency is critical.

Easy Integration

The PowerSSO-12 package of the VNN3NV04PTR-E is not only compact but also allows for efficient heat dissipation, which is crucial for maintaining performance in high-power systems. Its standardized package ensures compatibility with a wide range of PCB layouts, simplifying the integration process for designers and engineers.
