SG6840D System General
Same model may have multiple batches, images only for reference.

SG6840D

Part No SG6840D
Manufacturer System General
Catalog HOT - SALES and EOL Components (S)
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Manufacturer System General
Win Source Part Number 319760-SG6840D
Popularity Low
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian SG6840D CAD Model

Description

The SG6840D is a voltage mode PWM controller that is designed for off-line power supplies.

  • Function: Provides a fixed-frequency pulse-width modulation (PWM) that is used to regulate the output voltage of an off-line flyback converter
  • Features: Designed to operate from a wide input voltage range and has a built-in high-voltage startup circuit; also includes a soft-start function that limits the inrush current during startup
  • Applications: Ideal for use in applications such as LCD monitors, TVs, and other consumer electronics products
