BZD27C10P Vaishali Semiconductor
Same model may have multiple batches, images only for reference.

BZD27C10P

Part No BZD27C10P
Manufacturer Taiwan Semiconductor
Catalog Diodes - Zener - Single
Description SUB SMA, 1000MW, 6%, ZENER DIODE
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Discrete Semiconductor Products - Diodes - Zener - Single Zener Diodes
Mfr Taiwan Semiconductor
Package Tape & Reel
Product Status Active
Voltage - Zener (Nom) (Vz) 10 V
Tolerance ±6%
Power - Max 1 W
Impedance (Max) (Zzt) 4 Ohms
Current - Reverse Leakage @ Vr 7 µA @ 7.5 V
Voltage - Forward (Vf) (Max) @ If 1.2 V @ 200 mA
Temperature Range - Operating -55°C ~ 175°C (TJ)
Mounting Type Surface Mount
Package / Case SOD-123
Supplier Device Package Sub SMA
Base Product Number BZD27
Standard Package 10,000 pcs
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.10.0050
Win Source Part Number 574256-BZD27C10P
Ultra Librarian 3D Model Ultra Librarian BZD27C10P CAD Model

Description

The 574256-BZD27C10P is a single zener diode designed for voltage regulation and protection in electronic circuits.

  • Zener Voltage: 10V
  • Tolerance: ±6%
  • Maximum Power Dissipation: 1W
  • Forward Voltage Drop: 1.2V @ 200mA
  • Reverse Leakage Current: 7µA @ 7.5V
  • Impedance: 4 Ohms
  • Mounting Type: Surface Mount
  • Package: SOD-123
  • Operating Temperature: -55°C to 175°C
