1-178314-5

Part No 1-178314-5
Manufacturer TE Connectivity
Catalog Rectangular Connectors
Description CONN HDR 4POS VERT KEY-X TIN
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Connectors, Interconnects
Manufacturer TE Connectivity AMP Connectors
Packaging Bulk
Status Active
Connector Type Header
Contact Type Tab
Pitch - Mating 0.150" (3.81mm)
Style Board to Board or Cable
Shrouding Shrouded - 4 Wall
Number of Positions 4
Number of Positions Loaded All
Number of Rows 1
Mounting Through Hole
Termination Solder
Fastening Type Detent Lock
Contact Length - Post 0.150" (3.81mm)
Insulation Height 0.850" (21.59mm)
Contact Shape Rectangular
Contact Finish - Mating Tin
Contact Finish Thickness - Mating 78.7μin (2.00μm)
Contact Finish - Post Tin
Insulation Material Thermoplastic, Polyester, Glass Filled
Features Board Lock
Temperature Range - Operating -55°C to 105°C
Material Flammability Rating UL94 V-0
Insulation Color Black
Voltage Rating 250V
Applications General Purpose, Industrial
Win Source Part Number 056913-1-178314-5
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian 1-178314-5 CAD Model

Description

Product Description

The 1-178314-5 connector is specifically crafted for applications that demand precision and high performance. This versatile component is adaptable to various systems and excels in maintaining stable connections.

Features and Benefits

  • Precision-engineered for accuracy and consistency
  • High resistance to wear and tear
  • Easy to install and remove
  • Excellent signal transmission capabilities

Applications

  • Networking hardware
  • Data acquisition systems
  • Power management applications
  • Robotics
  • Marine electronics

Choose the 1-178314-5 connector for solutions that require reliability and precision in connectivity.
