Products specifications Report Issue?

RoHS State Request Verification
Manufacturer TelCom Semiconductor, Inc
Win Source Part Number 1264810-TC7106
Manufacturer Homepage www.telcom-semi.com
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian TC7106 CAD Model

Description

The TC7106 is a monolithic analog-to-digital converter (ADC) integrated circuit manufactured by TelCom Semiconductor, Inc. (later acquired). It is specifically designed to drive LCD displays directly, making it a popular choice for low-power digital panel meters (DPMs) and other battery-powered instrumentation. The TC7106 integrates all the necessary components for a complete 3 1/2 digit ADC, including the analog input circuitry, reference voltage, clock oscillator, and LCD display drivers.

Applications:

  • Digital Panel Meters (DPMs)
  • Battery-powered instrumentation
  • Digital multimeters
  • Weighing scales
  • Thermometers
  • Process control indicators

Features:

  • Direct LCD display drive: Eliminates the need for external display drivers, simplifying circuit design and reducing component count.
  • Low power consumption: Ideal for battery-powered applications, extending battery life.
  • High input impedance: Minimizes loading effects on the input signal, ensuring accurate measurements.
  • Zero drift: Maintains accuracy over temperature variations.
  • Single power supply operation: Operates from a single voltage source, simplifying power supply requirements.
  • On-chip oscillator: Provides a stable clock signal without the need for external components.

Benefits:

  • Simplified system design: Integration of all necessary ADC functions reduces the number of external components, simplifying circuit layout and assembly.
  • Extended battery life: Low power consumption allows for prolonged operation in battery-powered devices.
  • Accurate measurements: High input impedance and zero drift ensure reliable and precise readings.
  • Cost-effective solution: Integrated functionality reduces component count and overall system cost.
  • Easy to use: Simple interface and minimal external components make the TC7106 easy to implement in various applications.

Additional Details:

The TC7106 typically provides a 3 1/2 digit display capability, meaning it can display values from -1999 to +1999. It utilizes a dual-slope integration technique for analog-to-digital conversion, which provides good noise rejection and accuracy. The device requires a reference voltage to establish the full-scale input range. The input voltage is typically scaled to match the reference voltage for optimal performance. The TC7106 is commonly available in DIP (Dual In-line Package) and SOIC (Small Outline Integrated Circuit) packages. For detailed specifications, such as input voltage range, conversion rate, and operating temperature, consult the manufacturer's datasheet.
