ADCS7476AIMF Real Image ADCS7476AIMF Real Image1 ADCS7476AIMF Real Image2 ADCS7476AIMF Real Image3
Same model may have multiple batches, images only for reference.
ADCS7476AIMF Real Image ADCS7476AIMF Real Image1 ADCS7476AIMF Real Image2 ADCS7476AIMF Real Image3
ADCS7476AIMF Real Image ADCS7476AIMF Real Image1 ADCS7476AIMF Real Image2 ADCS7476AIMF Real Image3
Same model may have multiple batches, images only for reference.

ADCS7476AIMF

Part No ADCS7476AIMF
Manufacturer Texas Instruments
Catalog Data Acquisition - Analog to Digital Converters (ADC)
Description 1-Channel Single ADC SAR 1Msps 12-bit Serial 6-Pin SOT-23 T/R / 1MSPS, 12-/1-/8-Bit A/D Converters in 6-Lead SOT-23
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Manufacturer Texas Instruments
Architecture SAR
Mounting Surface Mount
Operating Temp Range -4C to 125C
Package Type SOT-23
Packaging Tape and Reel
Pin Count 6
Rated Input Volt 5.25
Number of Elements 1
Input Type Voltage
Operating Temperature Classification Automotive
Differential Input No
Input Polarity Unipolar
Dual Supply Voltage (Typ) Not Required(V)
Power Supply Requirement Single
Dual Supply Voltage (Min) Not Required(V)
Rad Hardened No
Single Supply Voltage (Min) 2.7(V)
Single Supply Voltage (Max) 5.25(V)
Single Supply Voltage (Typ) 3.3/5(V)
Dual Supply Voltage (Max) Not Required(V)
Differential Linearity Error ±1LSB
Resolution 12Bit
Integral Nonlinearity Error -1.1LSB/1LSB(LSB)
Input Signal Type Single-Ended
Win Source Part Number 087953-ADCS7476AIMF
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Application Field Used in Wireless, Medical, Communications & Networking
Family Name ADCS7476
Introduction Date June 01, 2003
ECCN EAR99
Country of Origin Malaysia
Halogen Free Compliant
Estimated EOL Date 2031
Ultra Librarian 3D Model Ultra Librarian ADCS7476AIMF CAD Model

Description

ADCS7476AIMF Overview

The ADCS7476AIMF is a compact yet powerful ADC tailored for applications needing dependable fine-grain data conversion. It stands out for its quick response time and accurate digital output, meeting the demands of modern electronic systems.

  • Resolution: 12-bit precision
  • Package Type: Small footprint for easy PCB layout
  • Efficient Performance: Operates with minimal latency

Features and Benefits

  • Dependable Operation: Consistent performance under heavy usage
  • Quick Response: Ideal for time-sensitive applications
  • Compact Size: Suitable for space-restricted designs

Applications

  • Consumer Electronics
  • Automotive Systems
  • Instrumentation
