Product Overview: CD74ACT541SM96

The CD74ACT541SM96 is a high-performance, octal buffer/line driver designed by Texas Instruments to provide interface capability for multi-level bus structures. This integrated circuit is part of the ACT (Advanced CMOS Technology) family, offering a combination of speed and power efficiency that makes it an ideal choice for a wide range of applications, including memory drivers, clock drivers, and bus-oriented receivers and transmitters.

Key Features

• Logic Type: Octal Buffer/Line Driver with 3-State Outputs
• Number of Pins: 20-pin package
• Supply Voltage Range: 4.5V to 5.5V, making it compatible with TTL levels
• Operating Temperature Range: -40°C to 85°C, suitable for industrial environments
• Drive Capability: High-current outputs drive up to 15 LSTTL loads
• IC Package Type: Surface-Mount Device (SMD) in SOP (Small Outline Package) form
• RoHS Compliant: Yes, meeting environmental and regulatory standards

Performance and Quality

The CD74ACT541SM96 is characterized for operation from -40°C to 85°C. It features inputs and outputs on opposite sides of the package to facilitate board layout. The 3-state control gate is a CMOS input stage and the outputs are non-inverting. This ensures that the device has the capability to drive heavy load conditions without compromising on the speed or power consumption.

Applications

With its robust design and high drive capability, the CD74ACT541SM96 is suitable for a variety of applications, including:

• Bus Interface Buffers
• Data Communication Systems
• Control Systems
• Embedded Systems

Reliability and Support

Texas Instruments is known for its commitment to quality and reliability, and the CD74ACT541SM96 is no exception. Customers can expect comprehensive technical support and documentation, including datasheets, application notes, and design resources. This ensures a smooth integration of the product into various designs and applications.

Overall, the CD74ACT541SM96 by Texas Instruments stands out as a reliable and efficient solution for digital signal buffering and driving, backed by TI's reputation for quality and performance.
