LM1117MPX-5.0

Name: LM1117MPX-5.0
Brand: Texas Instruments
SKU: 181090
Availability: InStock
Rating: 4.85 (48 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	LM1117MPX-5.0
Manufacturer	Texas Instruments
Catalog	PMIC - Voltage Regulators - Linear
Description	IC REG LDO 5V 0.8A SOT223
Datasheet	LM1117MPX-5.0 Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Integrated Circuits
Manufacturer	Texas Instruments
Packaging	Reel - TR
Status	Not For New Designs
Output Type	Fixed
Number of Regulators	1
Maximum Input Voltage	15V
Nominal Output Voltage (Min/Fixed)	5V
Dropout Voltage-Max	1.2V @ 800mA
Output Current	800mA
Operating Supply Current	5mA to 10mA
PSRR	75dB (120Hz)
Control Protection Features	Over Current, Over Temperature
Temperature Range - Operating	0°C to 125°C
Regulator Topology	Positive Fixed
Output Voltage	5V
Voltage - Dropout (Typical)	1.2V @ 800mA
Mounting	SMD (SMT)
Case / Package	SOT-223-4
Win Source Part Number	092138-LM1117MPX-5.0
Family Name	LM1117
Introduction Date	July 19, 1999
ECCN	EAR99
Country of Origin	Malaysia
Halogen Free	Compliant
Estimated EOL Date	2028
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Sufficient
Application Field	Used in Power Management
Ultra Librarian 3D Model	Ultra Librarian LM1117MPX-5.0 CAD Model

Alternative Products

Description

The LM1117MPX-5.0 is an impressive product from Texas Instruments, a leading company in the global semiconductor industry.

Output Current: 800mA
Package: 3-pin SOT-223
Output Voltage: 5.0 volts
Safety Features: Current limiting and thermal shutdown
Operating Temperature Range: -40°C to 125°C
Power Supply Rejection Ratio (PSRR): High
