The LM2825N-12 is a highly efficient, integrated power supply module from Texas Instruments, designed to simplify the design of power systems. This versatile component integrates a switching regulator and multiple passive components, providing a compact power solution suitable for a wide range of applications.

Key Features

• Integrated Solution: The LM2825N-12 combines a switching regulator with inductors, capacitors, and diodes in a single package, reducing the number of external components required and simplifying the power supply design.
• Wide Input Voltage Range: It operates over a broad input voltage range from 4.5V to 40V, making it suitable for applications with varying input voltages.
• Fixed Output Voltage: This module provides a fixed output voltage of 12V, which is ideal for standardized systems that require a stable and regulated power supply.
• High Efficiency: With its integrated design, the LM2825N-12 offers high conversion efficiency, which is critical for reducing heat generation and improving system reliability.
• Adjustable Switching Frequency: The switching frequency can be adjusted up to 200 kHz, allowing designers to optimize the performance for their specific application.
• Protection Features: It includes built-in thermal shutdown and current limit protection, enhancing the safety and durability of the end product.

Applications

The LM2825N-12 is an ideal choice for a variety of applications, including:

• Telecommunication equipment
• Consumer electronics
• Automotive systems
• Industrial controls
• Portable devices

Technical Specifications

The LM2825N-12 from Texas Instruments represents a reliable and efficient solution for designers looking to streamline their power supply design with a compact, integrated module.
