The LM5026SDX/NOPB is a high-performance Pulse Width Modulation (PWM) controller from Texas Instruments, designed specifically for power supply systems that require high efficiency, reliability, and advanced control features. This integrated circuit is part of the LM5026 series and is packaged in a compact, surface-mountable form factor, making it an ideal choice for space-constrained applications.

Key Features

• Voltage Mode Control: The LM5026SDX/NOPB operates with voltage mode control, providing precise output regulation and easy loop compensation.
• Advanced Start-Up and Shutdown Sequences: The device includes programmable soft-start and soft-stop functions that ensure smooth power ramp-up and ramp-down, minimizing stress on the system during power cycling.
• Integrated Gate Drivers: It features robust integrated gate drivers for driving the power stage MOSFETs, reducing external component count and simplifying the design.
• Wide Input Voltage Range: The controller supports a wide input voltage range, accommodating various power supply specifications and ensuring versatility across different applications.
• Protection Features: Comprehensive protection features include under-voltage lockout, thermal shutdown, over-current protection, and short-circuit protection, enhancing system safety and reliability.
• Adjustable Switching Frequency: The switching frequency is adjustable, allowing designers to optimize the power supply for efficiency or for reduced electromagnetic interference (EMI).

Applications

The LM5026SDX/NOPB is suitable for a wide range of applications, including but not limited to:

• Telecommunications power supplies
• Industrial power systems
• Server and networking equipment
• Automotive and aerospace applications

Environmental and Quality Certifications

This device is compliant with various environmental standards, including RoHS and is offered in a lead-free package. It is also characterized for operation from -40°C to 125°C, ensuring performance across a broad range of temperature conditions.

The LM5026SDX/NOPB by Texas Instruments represents a robust and flexible solution for designers looking to create efficient and reliable power supplies for a multitude of applications.
