OPA2234UA Real Image OPA2234UA real image4279
Same model may have multiple batches, images only for reference.
OPA2234UA Real Image OPA2234UA real image4279
OPA2234UA Real Image OPA2234UA real image4279
Same model may have multiple batches, images only for reference.

OPA2234UA

Part No OPA2234UA
Manufacturer Texas Instruments
Catalog Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description IC OPAMP GP 350KHZ 8SOIC
Datasheet
OPA2234UA Datasheet
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Tube/Rail
Status Active
Amplifier Type General Purpose
Number of Circuits 2
Slew Rate 0.2 V/μs
Gain Bandwidth Product (GBP) 350kHz
Current - Input Bias 12nA
Voltage - Input Offset 70μV
Operating Supply Current 275μA
Channel Output Current 22mA
Supply Voltage - Operating 2.7 V to 36 V, ±1.35 V to 18 V
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package 8-SOIC
Win Source Part Number 026001-OPA2234UA
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian OPA2234UA CAD Model

Description

The OPA2234UA is a high-performance operational amplifier from Texas Instruments, a renowned global semiconductor company.

  • Package: 8-pin SOIC
  • Power Supply Range: 2.7V to 5.5V
  • Quiescent Current: 500 µA
  • Offset Voltage: 150 µV
  • Common-Mode Rejection Ratio (CMRR): 114 dB
  • Power Supply Rejection Ratio (PSRR): 114 dB
  • Bandwidth: 1.8 MHz
  • Slew Rate: 0.8 V/µs
  • Input Bias Current: 1 pA
  • Input Noise Voltage: 8 nV/√Hz
  • Operation Range: -40°C to +85°C
