Products specifications

Category Integrated Circuits (ICs) - Interface - UARTs (Universal Asynchronous Receiver Transmitter)
Mfr Texas Instruments
Package Tape & Reel
Product Status Obsolete
Number of Channels 2, DUART
FIFO's 16 Byte
Data Rate (Max) 1.5Mbps
Voltage - Supply 5V
With False Start Bit Detection Yes
With Modem Control Yes
Mounting Type Surface Mount
Package / Case 44-LCC (J-Lead)
Supplier Device Package 44-PLCC (16.58x16.58)
Base Product Number PC16552
Standard Package 500 pcs
MSL Level 2A (4 Weeks)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001
Win Source Part Number 652960-PC16552DVX
Ultra Librarian 3D Model Ultra Librarian PC16552DVX CAD Model

Description

The PC16552DVX is a high-performance integrated circuit from Texas Instruments that is designed to provide a reliable, dual-channel UART (Universal Asynchronous Receiver/Transmitter) interface. This advanced IC is ideal for applications that require fast and efficient serial data communication, making it a popular choice for a variety of industrial, telecommunications, and consumer electronics systems.

Key Features

  • Dual Channel: The PC16552DVX features two independent UART channels, which can be used simultaneously for increased data throughput or to handle separate serial communication tasks.
  • High Data Rates: Each UART channel is capable of supporting data rates up to 1.5 Mbps, allowing for high-speed data transmission and reception.
  • FIFO Buffers: Built-in 16-byte FIFO buffers for both transmit and receive operations help to reduce the load on the CPU and improve system efficiency by managing bursts of data.
  • Programmable Baud Rate Generators: The baud rate for each channel can be independently programmed to match specific communication requirements.
  • Modem Control Functions: Integrated modem control functions provide the necessary signals for full modem interface capability, simplifying design for telecommunications applications.
  • Flexible Character Formatting: It supports 5, 6, 7, or 8-bit characters, with even, odd, or no parity, and 1, 1.5, or 2 stop bit selection.
  • Industrial Temperature Range: The device operates over an industrial temperature range, making it suitable for harsh operating environments.

Applications

The versatility of the PC16552DVX allows it to be used in a wide array of applications, including:

  • Industrial control systems
  • Networking equipment, such as routers and switches
  • Point-of-sale (POS) terminals
  • Data acquisition systems
  • Server and workstation serial communication ports

With its robust feature set and reliable performance, the PC16552DVX from Texas Instruments stands out as a superior choice for designers and engineers looking to implement efficient serial communication in their products.
