SN74AHCT594PW

Part No SN74AHCT594PW
Manufacturer Texas Instruments
Catalog Logic - Shift Registers
Description IC SHIFT REGISTER 8BIT 16-TSSOP / Shift Shift Register 1 Element 8 Bit 16-TSSOP
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Integrated Circuits (ICs)>Logic - Shift Registers
Mfr Texas Instruments
Series 74AHCT
Package Tube
Logic Type Shift Register
Output Type Push-Pull
Number of Elements 1
Number of Bits per Element 8
Function Serial to Parallel
Voltage - Supply 4.5V ~ 5.5V
Temperature Range - Operating -40°C ~ 85°C
Mounting SMD (SMT)
Package / Case 16-TSSOP (0.173", 4.40mm Width)
Supplier Device Package 16-TSSOP
Base Product Number 74AHCT594
Other Names TEXTISSN74AHCT594PW,296-33694-5,SN74AHCT594PWE4,SN74AHCT594PW,SN74AHCT594PWG4,SN74AHCT594PWE4,SN74AHCT594PWG4,2156-SN74AHCT594PW
Standard Package 90
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001
Win Source Part Number 1257125-SN74AHCT594PW
Ultra Librarian 3D Model Ultra Librarian SN74AHCT594PW CAD Model

Description

Product Overview: SN74AHCT594PW by Texas Instruments

The SN74AHCT594PW is a high-performance integrated circuit designed and manufactured by the renowned electronics company, Texas Instruments. This device is part of the 'AHCT' family, which stands for Advanced High-Speed CMOS Technology, indicating that it is built using a modern CMOS process that provides both high speed and low power consumption.

The SN74AHCT594PW is an 8-bit shift register with a storage function. Its primary purpose is to capture serial data and then provide parallel output. This makes it an ideal choice for applications that require the conversion of serial input data to parallel output data, such as in data communication systems, digital signal processing, and control systems.

This device features a wide operating voltage range of 4.5 to 5.5 volts, which allows for flexible integration into various circuit designs. Additionally, the SN74AHCT594PW boasts a significant feature: the ability to operate at high speeds while maintaining low power dissipation. This balance between speed and efficiency is critical in modern electronic devices, where energy conservation is as important as performance.

The SN74AHCT594PW comes in a TSSOP (Thin Shrink Small Outline Package) with 16 pins, making it compact and suitable for space-constrained applications. The package is designed for surface mounting, which facilitates easier assembly and soldering onto printed circuit boards.

Texas Instruments ensures the reliability and performance of the SN74AHCT594PW by subjecting it to rigorous testing and quality control measures. The device also meets or exceeds industry standards for shift registers, ensuring compatibility and interoperability in a wide range of applications.

In summary, the SN74AHCT594PW from Texas Instruments is a versatile, high-speed 8-bit shift register that offers low power dissipation, a wide operating voltage range, and a compact TSSOP-16 package. It is an excellent choice for designers looking to incorporate reliable serial-to-parallel data conversion functionality into their electronic systems.
