Product Overview

The SN74LVC244ADBRG4 from Texas Instruments is a robust, high-performance octal buffer/line driver designed to provide the ideal solution for driving bus lines or buffering memory address registers. This integrated circuit is part of the LVC family, which is known for its low-voltage operation and high-speed interfacing capabilities.

Key Features

• Wide Operating Voltage Range: The SN74LVC244ADBRG4 operates at a voltage range of 2.7V to 3.6V, making it suitable for interfacing with 3.3V logic levels while maintaining 5V tolerant inputs.
• High Drive Capability: With the ability to source and sink up to 24 mA, this octal buffer can drive multiple loads simultaneously, ensuring strong signal integrity.
• Low Power Consumption: It is designed for low power consumption, featuring a typical ICC of only 4 µA, which is ideal for power-sensitive applications.
• Bus Hold on Data Inputs: The device includes a bus hold feature on its data inputs, which eliminates the need for external pull-up or pull-down resistors and simplifies design.
• High-Speed Performance: The SN74LVC244ADBRG4 boasts a high-speed data transfer capability, making it suitable for high-frequency signal buffering.

Applications

The versatility of the SN74LVC244ADBRG4 makes it a perfect choice for a wide range of applications, including:

• Bus driving for memory and address registers in computer systems
• Buffering and driving signals for backplane and bus lines
• Supporting high-speed data transmission in telecommunications
• Interfacing and level shifting in multi-voltage systems
• General-purpose logic buffering

Package and Quality

Encased in a SSOP (Shrink Small Outline Package), the SN74LVC244ADBRG4 is designed for space-constrained applications. The device is also RoHS compliant, ensuring adherence to environmental standards. Texas Instruments' commitment to quality means that this product meets the stringent requirements of the semiconductor industry, providing reliability and performance for critical applications.

With its combination of features, the SN74LVC244ADBRG4 from Texas Instruments is an excellent choice for designers looking for a high-quality, versatile octal buffer/line driver for their next project.
