The SN75240PWR is a robust, high-performance dual USB port transient suppressor designed and manufactured by Texas Instruments (TI). This component is engineered to provide reliable protection for sensitive electronics against electrostatic discharges (ESD), electrical fast transients (EFT), and other voltage-induced transients that are commonly encountered in USB applications.

Key Features

• Transient Protection: The SN75240PWR offers transient voltage suppression for both USB1 and USB2 power lines, safeguarding against surges up to 15kV (Human Body Model) and 8kV (IEC 61000-4-2, Contact Discharge).
• Compatibility: It is fully compatible with USB 1.1 and 2.0 standards, ensuring seamless integration into existing and new USB designs.
• Low Capacitance: The device features low-capacitance diodes, which are essential for maintaining signal integrity, especially at high data rates characteristic of USB 2.0.
• Compact Package: Housed in a small 8-pin TSSOP (Thin Shrink Small Outline Package), the SN75240PWR is ideal for space-constrained applications.

Applications

The versatility of the SN75240PWR makes it suitable for a wide array of applications. It is particularly useful in:

• USB Hub, Ports, and Peripherals
• Desktop and Laptop Computers
• Consumer Electronics
• Portable Device Docks
• Set-Top Boxes

Reliability and Quality

Texas Instruments is known for its commitment to quality and reliability. The SN75240PWR is no exception, undergoing rigorous testing to ensure it meets the high standards expected from TI components. Users can trust this device to provide consistent performance and durability.

Environmental and Regulatory Compliance

The SN75240PWR is RoHS compliant, meaning it adheres to strict European Union standards regarding the restriction of hazardous substances. This compliance ensures that the product is environmentally friendly and can be used in applications sold within the EU and other regions that recognize RoHS standards.
