The TLC272CDR is a precision operational amplifier (op-amp) from Texas Instruments, designed to meet a wide range of applications with its exceptional features. This dual op-amp comes in an 8-pin SOIC package, offering a compact solution for space-constrained applications.

Key Features

• High Precision: The TLC272CDR provides high-level accuracy, which makes it ideal for precision analog applications.
• Low Power Consumption: It is designed for low power operation, which is critical for battery-powered and portable devices, ensuring longer operational life and reliability.
• Wide Supply Range: This op-amp operates with a supply voltage range from 4 V to 16 V, making it versatile for various electronic circuits and systems.
• Output Drive Capability: It can drive loads as capacitive as 10,000 pF, which is beneficial for driving larger capacitive loads without compromising performance.
• Low Offset Voltage: The device features a low input offset voltage, which reduces error in amplification, thereby enhancing overall system accuracy.

Applications

The TLC272CDR is suitable for a multitude of applications, including:

• Test equipment
• Signal conditioning
• Data acquisition systems
• Analog filters
• Consumer electronics
• Medical instruments

Quality and Reliability

Texas Instruments is renowned for its commitment to quality and the TLC272CDR is no exception. It is built to meet the rigorous standards of the industry, ensuring high reliability and performance consistency over a wide range of operating conditions.

Environmental Considerations

The TLC272CDR is RoHS compliant, meaning it is manufactured with a focus on environmental safety by restricting the use of certain hazardous substances. This commitment to environmental stewardship makes it suitable for use in a variety of markets worldwide, including those with strict environmental regulations.
