The TLE2072CDR from Texas Instruments is a high-performance, dual operational amplifier (op-amp) that comes in an 8-pin SOIC package. This device is part of the Excalibur low-noise, high-speed operational amplifier series, which is designed to offer a combination of low noise, high speed, and wide bandwidth, making it suitable for a variety of demanding applications.

Key Features

• Low Noise: The TLE2072CDR features a low noise voltage of 9 nV/√Hz at f = 1 kHz, which makes it ideal for high-fidelity audio applications and sensitive instrumentation that require minimal signal distortion.
• High Speed: With a slew rate of 3.6 V/µs, this op-amp is capable of handling rapid signal changes, providing the accuracy needed for high-speed data acquisition and video processing.
• Wide Bandwidth: The device offers a wide bandwidth of 10 MHz, enabling it to process a broad range of frequencies without significant signal loss or degradation.
• Low Input Bias Current: The very low input bias current of 2 pA ensures minimal error in applications with high source impedances.
• Supply Voltage Range: It operates over a wide supply voltage range of ±5V to ±15V, allowing for flexibility in both single and dual supply configurations.

Applications

The TLE2072CDR is versatile and can be used in various applications, including:

• Professional audio equipment
• Active filters
• Fast operational amplifier circuits
• Precision analog circuits
• Data acquisition systems
• Instrumentation

Quality and Reliability

Texas Instruments is known for its commitment to quality and reliability, and the TLE2072CDR is no exception. This product is designed and manufactured to meet the highest standards, ensuring stable and consistent performance across a wide range of environmental conditions.

Ordering Information

The TLE2072CDR is available for order directly from Texas Instruments or through authorized distributors. For detailed product specifications, application notes, and support resources, please visit the Texas Instruments website or contact their customer support team.
