Products specifications

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Type Transceiver
Protocol IEEE 802.3
Number of Drivers/Receivers 1/1
Duplex Full
Supply Voltage - Operating 2.3 V to 2.7 V
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package 64-HVQFP
Win Source Part Number 032821-TLK2201BIRCPR
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian TLK2201BIRCPR CAD Model

Description

Overview of Texas Instruments TLK2201BIRCPR

The TLK2201BIRCPR is a high-performance, versatile serializer/deserializer (SerDes) transceiver from Texas Instruments, specifically designed to address the needs of high-speed bidirectional point-to-point data transmission systems. This advanced product is part of the TLK2201 family and is an ideal solution for applications that require fast data transfer rates and reliable communication over copper or fiber optic cables.

Key Features

  • High Data Rate: The TLK2201BIRCPR supports a wide range of data rates from 0.6 Gbps to 2.5 Gbps, making it suitable for various applications, including Gigabit Ethernet, Fibre Channel, and InfiniBand.
  • Flexibility: It offers a flexible interface with both 16-bit and 20-bit data bus widths, allowing for easy integration with different types of hardware.
  • Signal Integrity: With its built-in equalization and clock data recovery (CDR), the TLK2201BIRCPR ensures robust signal integrity even over long cable lengths or through challenging transmission media.
  • Low Power Consumption: Designed for efficiency, it operates with a low power consumption, which is critical for thermal management and power savings in dense electronic systems.
  • Hot-Plug Capability: The device features hot-plug protection that prevents damage to the transceiver during cable insertion or removal when the system is powered on.
  • Industrial Temperature Range: It is rated for an industrial temperature range of -40°C to 85°C, ensuring reliable performance under extreme temperature conditions.

Applications

The TLK2201BIRCPR is suitable for a broad array of applications, including:

  • Data center interconnects
  • High-speed backplanes
  • Telecommunications equipment
  • Professional video equipment
  • Storage area networks (SAN)
  • Proprietary data transport systems

Package and Quality

The TLK2201BIRCPR is offered in a compact 64-pin QFN package, which is designed to save board space and support high-density mounting requirements. Texas Instruments is known for its commitment to quality, and this product meets stringent industry standards for performance and reliability.

With its combination of high-speed data transmission, signal integrity, and design flexibility, the TLK2201BIRCPR from Texas Instruments is an exceptional choice for engineers and system designers looking to enhance their high-speed communication systems.
