Product Overview: Texas Instruments TLV2761IDBVR

The Texas Instruments TLV2761IDBVR is a high-precision, low-power operational amplifier that is part of the TLV276x family. This single-channel op-amp is designed to operate with a power supply range of 2.7V to 5.5V, making it an ideal choice for battery-powered and portable applications where power efficiency is critical.

Encased in a compact SOT-23-5 package, the TLV2761IDBVR is optimized for space-constrained designs, while still delivering robust performance. With a low quiescent current of just 500 µA per channel, this op-amp helps to extend battery life in mobile devices. Despite its low power consumption, the TLV2761IDBVR does not compromise on speed, featuring a slew rate of 0.62 V/µs and a bandwidth of 5.5 MHz, ensuring responsive operation in a variety of circuits.

One of the key features of the TLV2761IDBVR is its Rail-to-Rail output, which allows the output to swing within millivolts of the supply rails, maximizing the dynamic range in analog circuits. This feature, combined with an input common-mode voltage range that includes ground, provides designers with greater flexibility in single-supply applications.

The device also boasts a low input bias current of 1 pA, which minimizes errors in high-impedance applications, making it suitable for sensor interfaces, A/D convertor buffers, and other precision circuits. The op-amp's low input offset voltage of 1.5 mV ensures high accuracy, reducing the need for external calibration in many applications.

Furthermore, the TLV2761IDBVR is characterized for operation from –40°C to 125°C, which allows reliable performance across a wide range of temperature conditions. Its robust design includes built-in ESD protection, ensuring the device's resilience in the face of electrostatic discharges.

In summary, the Texas Instruments TLV2761IDBVR is a versatile, high-performance operational amplifier that combines low power consumption with high precision. Its small footprint, Rail-to-Rail output, and wide operating temperature range make it an excellent choice for designers working on portable electronics, instrumentation, and other power-sensitive applications.
