Products specifications

Category Sensors, Transducers>Temperature Sensors - Thermostats - Solid State
Mfr Texas Instruments
Package Tape & Reel
Trip Temperature Threshold Cold, Hot
Switching Temperature Programmable
Accuracy ±3°C
Output Type Open Drain
Output Active Low
Output Function OverTemp
Selectable Hysteresis Yes
Features Selectable Trip Point
Voltage - Supply 1.62 V ~ 5.5 V
Current - Supply 500nA
Temperature Range - Operating -55°C ~ 130°C
Mounting SMD (SMT)
Package / Case SOT-563, SOT-666
Base Product Number TMP390
Other Names 296-TMP390A2DRLRTR,296-TMP390A2DRLRDKR,296-TMP390A2DRLRCT
Standard Package 4,000
MSL Level 2 (1 Year)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001
Win Source Part Number 1233862-TMP390A2DRLR
Ultra Librarian 3D Model Ultra Librarian TMP390A2DRLR CAD Model

Description

Product Overview: Texas Instruments TMP390A2DRLR

The Texas Instruments TMP390A2DRLR is a precision, low-power, two-channel temperature switch with a factory-set temperature threshold. Designed to offer reliable and accurate temperature monitoring, this device is ideal for a wide range of applications, including industrial, consumer, and computing systems.

Key Features

  • Accuracy: The TMP390A2DRLR boasts a high degree of accuracy, with a typical threshold accuracy of ±1°C, ensuring precise temperature monitoring and control.
  • Low Power Consumption: Optimized for battery-powered and low-power applications, the device operates with a very low quiescent current that significantly reduces power consumption.
  • Dual-Channel: Equipped with two independent temperature-sensing channels, the TMP390A2DRLR allows for simultaneous monitoring of two separate temperature zones, enhancing system safety and reliability.
  • Programmable Temperature Thresholds: The temperature thresholds are factory-programmed and offer a range of settings to accommodate various application requirements.
  • Output Signal: The open-drain output provides a simple interface to external circuits, allowing the TMP390A2DRLR to easily integrate with other system components.
  • Supply Voltage Range: The device supports a wide supply voltage range from 1.8V to 5.5V, making it versatile for use in various circuit designs.

Applications

The TMP390A2DRLR is suitable for a variety of applications that require reliable temperature monitoring. Some common applications include:

  • Overtemperature protection for ICs and electronic systems
  • Battery management systems
  • Environmental monitoring and HVAC systems
  • Consumer electronics such as laptops and smartphones
  • Industrial equipment monitoring

Package and Availability

The TMP390A2DRLR is available in a compact 6-pin SOT (R-PDSO-G) package, making it easy to incorporate into space-constrained designs. It is part of Texas Instruments' commitment to providing high-quality, reliable components for a wide range of temperature monitoring solutions.

With its combination of precision, low power, and dual-channel operation, the Texas Instruments TMP390A2DRLR is a versatile temperature switch that can meet the needs of a multitude of temperature-sensitive applications.
