Products specifications

Categories Sensors, Transducers
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Sensor Type Digital, Local/Remote
Sensing Temperature - Local -40°C to 125°C
Sensing Temperature - Remote -64°C to 191°C
Output Type SMBus
Supply Voltage - Operating 2.7 V to 5.5 V
Resolution 11 b
Features One-Shot, Output Switch, Programmable Limit, Shutdown Mode
Accuracy - Highest (Lowest) ±1.5°C (±2.5°C)
Testing Conditions 15°C to 85°C (-40°C to 125°C)
Temperature Range - Operating -40°C to 125°C
Mounting SMD (SMT)
Case / Package SOT-23-8
Win Source Part Number 033255-TMP421AIDCNT
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Application Field Used in Sensing & Instrumentation, Computers & Computer Peripherals, Communications & Networking
Ultra Librarian 3D Model Ultra Librarian TMP421AIDCNT CAD Model

Description

The TMP421AIDCNT is a high-precision temperature sensor developed by Texas Instruments (TI), designed for applications that require accurate temperature monitoring with digital output. This device is part of TI's extensive family of temperature sensors, offering a combination of advanced features and high performance that make it suitable for a wide range of applications, including industrial, consumer, and computing environments.

Key Features

  • Accuracy: The TMP421AIDCNT provides exceptional accuracy with a typical accuracy of ±1°C over a temperature range of -40°C to +125°C.
  • Interface: It features a two-wire, SMBus and I²C-compatible serial interface, which simplifies integration into existing systems and allows for easy communication with microcontrollers and other digital systems.
  • Supply Voltage: Operating from a supply voltage range of 2.7V to 5.5V, this sensor is versatile and can be used in various power environments.
  • Extended Temperature Range: The TMP421AIDCNT is capable of measuring temperatures from -40°C to +125°C, making it suitable for environments with wide temperature variations.
  • Programmable Resolution: It offers programmable resolution from 9 to 12 bits, allowing users to optimize the trade-off between resolution and conversion time according to their specific needs.
  • Remote Sensing: The device supports remote temperature sensing by using a diode-connected transistor, which can be useful for monitoring the temperature of various components or points within a system.

Applications

The TMP421AIDCNT is ideal for several applications where temperature monitoring is critical. These include:

  • Telecommunications equipment
  • Computer peripherals
  • Environmental monitoring
  • Industrial controls
  • Medical and healthcare systems
  • Electronic test equipment

Package and Quality

The TMP421AIDCNT comes in a compact SOT-23 package, making it easy to incorporate into space-constrained designs. Texas Instruments is known for its commitment to quality, and this product is no exception. It is designed to meet the high standards of reliability and performance that customers expect from TI products.
