TPS2041BDBVT

Part No TPS2041BDBVT
Manufacturer Texas Instruments
Catalog PMIC - Power Distribution Switches, Load Drivers
Description IC PWR DIST SWITCH SNGL SOT23-5
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Switch Type General Purpose
Number of Outputs 1
Output Type N-Channel
Voltage - Load 2.7 V to 5.5 V
Supply Voltage - Operating Not Required
Current - Output (Max) 500mA
Rds On (Typ) 95 mOhm
Input Type Non-Inverting
Features Status Flag
Fault Protection Current Limiting (Fixed), Over Temperature, UVLO
Temperature Range - Operating -40°C to 125°C (TJ)
Case / Package SOT-23-5
Win Source Part Number 033606-TPS2041BDBVT
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian TPS2041BDBVT CAD Model

Description

Overview of Texas Instruments TPS2041BDBVT

The TPS2041BDBVT is a single-channel, current-limited, power-distribution switch designed by Texas Instruments to enhance the system reliability in USB and other hot-swap applications. This compact device is housed in a SOT-23-6 package, making it an ideal solution for space-constrained applications.

Key Features

  • Current Limiting: The switch provides a precise current limit to prevent damage to host devices due to overcurrent conditions, which is particularly crucial in USB power distribution.
  • Thermal Shutdown Protection: It includes a thermal shutdown feature that protects the device and the downstream components from overheating.
  • Fast Transient Response: The TPS2041BDBVT is designed to handle fast transients, ensuring stable power delivery even under fluctuating load conditions.
  • Reverse Voltage Protection: This power switch prevents damage to the circuit by blocking the flow of current if the input voltage is reversed.
  • Under-Voltage Lockout (UVLO): The UVLO feature ensures that the switch remains off if the input voltage is below a certain threshold, safeguarding the system from low voltage conditions.

Applications

The TPS2041BDBVT is versatile and can be used in a variety of applications, including:

  • USB hubs, peripherals, and powered ports
  • Hot-swap power supplies
  • Battery-charger circuits
  • Portable consumer electronics

Performance Specifications

With an input voltage range of 2.7V to 5.5V, the TPS2041BDBVT caters to common USB power specifications. The device is capable of continuous output current up to 500mA, which is suitable for USB low-power and high-power devices. Additionally, it features a built-in charge pump that reduces the number of external components required for operation.

Quality and Reliability

As with all Texas Instruments products, the TPS2041BDBVT is manufactured to meet high standards of quality and reliability. This ensures that the device can be integrated into critical systems with confidence, knowing that it will perform as expected under various conditions.

For engineers and designers looking for a robust power management solution, the TPS2041BDBVT from Texas Instruments offers a reliable and efficient option that is easy to integrate into a wide range of electronic systems.
