TGA8659-FL Real Image1 TGA8659-FL Real Image2
Same model may have multiple batches, images only for reference.
TGA8659-FL Real Image1 TGA8659-FL Real Image2
TGA8659-FL Real Image1 TGA8659-FL Real Image2
Same model may have multiple batches, images only for reference.

TGA8659-FL

Part No TGA8659-FL
Manufacturer TriQuint Semiconductor
Description RF Amp Module Single Power Amp 15GHz 8V 10-Pin FL-A1
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Frequency 15 GHz
Gain 25 dB
Max Operating Temperature 150 °C
Max Power Dissipation 13.6 W
Max Supply Voltage 8 V
Mount Screw
Number of Channels 1
Number of Pins 10
Operating Supply Current 1.3 A
Operating Supply Voltage 7 V
Radiation Hardening No
RoHS Compliant
Test Frequency 15 GHz
Win Source Part Number 1146019-TGA8659-FL
Categories Custom Parts
Manufacturer TriQuint Semiconductor
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian TGA8659-FL CAD Model

Description

The TriQuint Semiconductor 1146019-TGA8659-FL is a custom part with a gain of 25dB and an operating frequency of 15GHz.

  • Gain: 25dB
  • Operating Frequency: 15GHz
  • Channel: Single
  • Pins: Ten
  • Mount: Screw
  • Operating Supply Voltage: 7V
  • Current: 1.3A
  • Maximum Power Dissipation: 13.6W
  • Maximum Supply Voltage: 8V
  • Maximum Operating Temperature: 150°C
  • RoHS Compliant: Yes
  • Popularity: Medium
  • Supply and Demand Status: Limited
