OP181 Real Image
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Category Optoelectronics - LED Emitters - Infrared, UV, Visible
Mfr TT Electronics
Package Tape & Reel
Product Status Obsolete
Type Infrared (IR)
Current - DC Forward (If) (Max) 50mA
Wavelength 940nm
Voltage - Forward (Vf) (Typ) 1.55V
Viewing Angle 30°
Orientation Top View
Temperature Range - Operating -40°C ~ 85°C (TA)
Mounting Type Surface Mount
Package / Case 2-SMD, Z-Bend, Bottom Entry
Standard Package 2,000 pcs
MSL Level 4 (72 Hours)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.41.0000
Win Source Part Number 650380-OP181
Ultra Librarian 3D Model Ultra Librarian OP181 CAD Model

Description

The 650380-OP181 is an infrared LED emitter from TT Electronics. It emits infrared (IR) light with a wavelength of 940nm.

  • Manufacturer: TT Electronics
  • Wavelength: 940nm
  • Current Forward: 50mA
  • Viewing Angle: 30°
  • Forward Voltage: Typically 1.55V
  • Package: 2-SMD, Z-Bend, bottom entry
  • Operating Temperature Range: -40°C to 85°C
  • ECCN: EAR99
  • Status: Obsolete
