Products specifications Report Issue?

RoHS State Request Verification
Manufacturer Wing Shing Computer Components
Win Source Part Number 1126405-2SD200
Manufacturer Homepage www.wingshing.com/en
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian 2SD200 CAD Model

Description

The 2SD200 is a silicon NPN transistor. While specific details from Wing Shing Computer Components are limited, this transistor is typically used in various switching and amplification applications. Its general characteristics make it suitable for use in power supplies and motor control circuits.

Applications

  • Switching Regulators: Used in switching regulators to provide stable voltage output.
  • Motor Control Circuits: Used to drive small DC motors in various applications.
  • Power Amplifiers: Used as a driver transistor in audio amplifiers.
  • General Purpose Switching: Suitable for general purpose switching applications.

Features

  • NPN Transistor: Common type of transistor for switching and amplification.
  • Medium Power Dissipation: Suitable for moderate power applications.
  • High Collector Current: Can handle moderate collector current.

Benefits

  • Stable Switching: Provides stable switching in regulator circuits.
  • Reliable Motor Control: Offers reliable motor control.
  • Efficient Amplification: Provides efficient amplification.

Additional Details

Typical specifications for a 2SD200 transistor include a collector-emitter voltage (VCEO) in the range of 50-80V, a collector current (IC) of around 2-3A, and a power dissipation (PC) of 20-30W, depending on the manufacturer's specific design. It is typically available in a TO-220 or similar package.
