Products specifications Report Issue?

RoHS State Request Verification
Manufacturer Wing Shing Computer Components
Win Source Part Number 1133718-78L12
Manufacturer Homepage www.wingshing.com/en
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian 78L12 CAD Model

Description

The 78L12 is a three-terminal positive voltage regulator. Part of the 78Lxx series, it provides a fixed output voltage of 12V, making it suitable for various electronic applications requiring a stable voltage source. It is known for its compact size, ease of use, and internal protection features.

Applications

  • Power supplies for small electronic devices
  • Regulation for microcontrollers and digital logic circuits
  • Post-regulation for switching power supplies
  • Battery chargers
  • Consumer electronics

Features

  • Fixed Output Voltage: Provides a stable 12V output
  • Low Quiescent Current: Minimizes power consumption
  • Short-Circuit Protection: Protects the regulator and connected circuitry from damage
  • Thermal Overload Protection: Prevents overheating and potential failures
  • Output Transistor Safe-Area Compensation: Enhances reliability

Benefits

  • Stable Voltage: Ensures consistent performance of connected devices
  • Simplified Design: Requires minimal external components
  • Protection Features: Prevents damage due to overcurrent and overheating
  • Low Power Consumption: Extends battery life in portable applications
  • Compact Size: Suitable for space-constrained designs

Additional Details

The 78L12 typically comes in a TO-92 or SO-8 package. The input voltage should be greater than the output voltage, with a typical range of 14.5V to 30V. The output current is limited to around 100mA. The regulator provides internal current limiting, thermal shutdown, and safe area compensation, making it a robust and reliable component. Proper heat sinking may be required, depending on the input voltage and output current, to prevent overheating. Datasheets provide detailed information on electrical characteristics, thermal considerations, and application circuits.
