STMicroelectronics M74HC4052RM13TR Analog Multiplexer/Demultiplexer

The M74HC4052RM13TR is a versatile dual 4-channel analog multiplexer/demultiplexer from the renowned semiconductor manufacturer STMicroelectronics. This integrated circuit is part of the high-speed CMOS family and is designed to provide the utmost flexibility in routing analog signals in various electronic applications.

This multiplexer/demultiplexer (mux/demux) IC features two independent 4-channel selectors and a binary address decoding scheme to select a single channel for each 4-channel section. The device is capable of handling both digital and analog signals, and it allows any of these signals to be routed to a single output, making it incredibly useful for signal processing tasks.

Key Features:

• Wide Operating Voltage Range: The M74HC4052RM13TR operates over a wide voltage range from 2V to 6V, making it suitable for interfacing with both TTL and CMOS logic levels.
• Low Power Consumption: Its CMOS technology ensures low power dissipation, which is a critical parameter for battery-powered and energy-saving applications.
• High Noise Immunity: The high noise immunity characteristic of CMOS technology is embedded in this device, ensuring reliable performance in electrically noisy environments.
• Low "ON" Resistance: It features a low "ON" resistance, which minimizes signal attenuation when routing through the switch.
• Wide Analog Input Voltage Range: The device can handle a wide range of analog input voltages, which spans from VCC- to VCC+, providing flexibility in interfacing with different signal levels.

The M74HC4052RM13TR is available in a compact surface-mount SOP-16 package, which is ideal for space-constrained applications. Its robust design and industry-standard footprint make it easy to integrate into a wide array of electronic systems, from simple signal routing tasks to more complex analog signal processing.

Whether it's for use in communication systems, data acquisition, test equipment, or consumer electronics, the M74HC4052RM13TR from STMicroelectronics offers a reliable and efficient solution for your analog signal multiplexing and demultiplexing needs.

For detailed specifications and application notes, designers and engineers are encouraged to consult the datasheet available on the STMicroelectronics website or contact their technical support for further assistance.
