Products specifications Report Issue?

RoHS State Request Verification
Manufacturer Wing Shing Computer Components
Win Source Part Number 1133721-78L15
Manufacturer Homepage www.wingshing.com/en
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian 78L15 CAD Model

Description

The 78L15 is a positive voltage regulator belonging to the 78Lxx series, offering a fixed 15V output voltage. It is commonly employed in scenarios demanding a stable 15V supply at low current levels. Its inherent simplicity, dependability, and integrated protection mechanisms render it suitable for various applications from hobbyist projects to professional electronic systems.

Applications:

  • Portable electronic devices requiring 15V regulation
  • Low-power instrumentation
  • Sensor power supplies
  • Hobby electronics projects
  • Voltage regulation for op-amp circuits

Features:

  • Fixed 15V Output: Provides a consistent and accurate 15V DC voltage.
  • Low Quiescent Current: Minimizes wasted power, ideal for battery-powered devices.
  • Internal Current Limiting: Protects the regulator and connected circuitry from overcurrent conditions.
  • Thermal Shutdown: Safeguards the regulator by disabling output in response to excessive heat buildup.
  • Minimal External Components: Typically requires only input and output bypass capacitors for stable operation.

Benefits:

  • Stable Power: Delivers consistent 15V power, improving overall circuit performance.
  • Enhanced Protection: Integrated safety features guard against damage due to short circuits or overheating.
  • Simplified Implementation: Requires minimal external components, streamlining circuit design.
  • Cost-Effective Solution: Provides a reliable regulated voltage at a low cost.
  • Versatile Application: Suited for a wide array of low-power electronic projects.

Additional Details:

The 78L15 is usually found in a TO-92 package. Important specifications include the maximum input voltage (consult the datasheet), output current rating (typically around 100mA), and the dropout voltage. Adding small bypass capacitors (e.g., 0.1uF) at the input and output is recommended to reduce noise and improve stability. Refer to the component’s datasheet from Wing Shing Computer Components for detailed specifications.
