Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Category Filters - Common Mode Chokes
Mfr Wurth Electronics Inc
Series WE-SCC
Package Tape & Reel
Product Status Active
Filter Type Signal Line
Number of Lines 2
Impedance @ Frequency 40 kOhms @ 7 MHz
Inductance @ Frequency 100 µH @ 100 kHz
Current Rating (Max) 900mA
DC Resistance (DCR) (Max) 280mOhm
Voltage Rating - DC 80V
Temperature Range - Operating -40°C ~ 125°C
Mounting Type Surface Mount
Size / Dimension 0.492" L x 0.492" W (12.50mm x 12.50mm)
Height (Max) 0.256" (6.50mm)
Package / Case Horizontal, 4 PC Pad
Standard Package 500 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8548.00.0000
Win Source Part Number 857318-744282101
Ultra Librarian 3D Model Ultra Librarian 744282101 CAD Model

Description

The WE-SCC series from Wurth Electronics Inc is a signal line common mode choke filter.

  • Voltage Rating: 80V DC
  • Current Rating: 900mA (Maximum)
  • Size: 0.492" L x 0.492" W (12.50mm x 12.50mm)
  • Height: 0.256" (6.50mm)
  • Lines: 2
  • Impedance: 40 kOhms @ 7 MHz
  • Inductance: 100 µH @ 100 kHz
  • Mounting Type: Surface Mountable
  • Package/Case: Horizontal, 4 PC pad
  • Operating Temperature: -40°C to 125°C
  • Category: Common Mode Chokes
