PCI20-220M-RC Allied Components International
Same model may have multiple batches, images only for reference.

PCI20-220M-RC

Part No PCI20-220M-RC
Manufacturer Allied Components International
Catalog Fixed Inductors
Description 22uH +/-20% Power Chip Inductor
Datasheet
PCI20-220M-RC Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Inductors, Coils, Chokes - Fixed Inductors
Mfr Allied Components International
Series PCI20
Package Tape & Reel
Product Status Active
Inductance 22 µH
Tolerance ±20%
Current Rating (Amps) 800 mA
Current - Saturation (Isat) 700mA
Shielding Unshielded
DC Resistance (DCR) 370mOhm Max
Frequency - Self Resonant 20MHz
Temperature Range - Operating -40°C ~ 85°C
Inductance Frequency - Test 100 kHz
Mounting Type Surface Mount
Package / Case Nonstandard
Size / Dimension 0.260" L x 0.175" W (6.60mm x 4.45mm)
Height - Seated (Max) 0.115" (2.92mm)
Standard Package 1 pcs
MSL Level 1 (Unlimited)
REACH Status REACH info available upon request
HTSUS 8504.50.4000
Win Source Part Number 711634-PCI20-220M-RC
Ultra Librarian 3D Model Ultra Librarian PCI20-220M-RC CAD Model

Description

The PCI20 series fixed inductor is a compact and reliable component designed for various applications.

  • Size: 0.260" L x 0.175" W
  • Inductance: 22μH
  • Tolerance: ±20%
  • Current: 800mA
  • DC Resistance: 370mOhm max
  • Temperature Range: -40°C to 85°C
  • Mounting: Surface Mount
  • Package: Nonstandard
  • Frequency Self-Resonant: 20MHz
  • Manufacturer: Allied Components International
