AO4407A Alpha & Omega Semiconductor Inc. AO4407A Real Image AO4407A real image1846 AO4407A Real Image AO4407A label picture 2 AO4407A real image
Same model may have multiple batches, images only for reference.
AO4407A Alpha & Omega Semiconductor Inc. AO4407A Real Image AO4407A real image1846 AO4407A Real Image AO4407A label picture 2 AO4407A real image
AO4407A Alpha & Omega Semiconductor Inc. AO4407A Real Image AO4407A real image1846 AO4407A Real Image AO4407A label picture 2 AO4407A real image
Same model may have multiple batches, images only for reference.

AO4407A

Part No AO4407A
Manufacturer Alpha & Omega Semiconductor Inc.
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET P-CH 30V 12A 8SOIC / Trans MOSFET P-CH 30V 12A 8-Pin SOIC
Datasheet
AO4407A Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Alpha & Omega Semiconductor Inc.
Packaging Reel - TR
Status Active
Polarity P-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 30V
Continuous Drain Current at 25°C 12A (Ta)
Drive Voltage (Max Rds On, Min Rds On) 6V, 20V
Gate-Source Threshold Voltage 3V @ 250μA
Max Gate Charge 39nC @ 10V
Max Input Capacitance 2600pF @ 15V
Maximum Gate-Source Voltage ±25V
Power Dissipation (Max) 3.1W (Ta)
Maximum Rds On at Id,Vgs 11 mOhm @ 12A, 20V
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package 8-SOIC
Dimension 8-SOIC (0.154", 3.90mm Width)
Win Source Part Number 009740-AO4407A
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name AO4407A
Introduction Date April 30, 2008
ECCN EAR99
Country of Origin China
Halogen Free Compliant
Estimated EOL Date 2022
Ultra Librarian 3D Model Ultra Librarian AO4407A CAD Model

Description

AO4407A P-Channel MOSFET

The AO4407A is a P-channel MOSFET featuring low on-resistance and fast switching speeds, making it suitable for high-performance power applications where efficiency is critical.

  • Applications:
    • Switching regulators
    • Battery protection
    • Linear regulators
    • Motor control
  • Features and Benefits:
    • Low on-resistance for less power loss
    • Fast switching performance
    • Highly reliable under various temperature ranges
  • Additional Details:
    • V<sub>DS = -30V
    • I<sub>D = -12A
    • R<sub>DS(on) = 20mΩ @ V<sub>GS = -10V
