Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Categories Integrated Circuits (ICs)
Manufacturer Altera
Series Cyclone V E
Number of LABs/CLBs 9434
Number of Logic Elements/Cells 25000
Total RAM Bits 2002944
Number of I/O 224
Operating Supply Voltage 1.07 V ~ 1.13 V
Mounting SMD
Operating Temperature Range 0°C ~ 85°C (TJ)
Package 484-BGA
Manufacturer Package 484-FBGA (23x23)
Win Source Part Number 764197-5CEFA2F23C8N
Popularity Medium
Supply and Demand Status Limited
Quantity per package 60
Ultra Librarian 3D Model Ultra Librarian 5CEFA2F23C8N CAD Model

Description

The Altera 764197-5CEFA2F23C8N is a member of the Cyclone V E series of FPGAs, designed for use in a variety of electronic applications.

  • I/O Pins: 224
  • LABs/CLBs: 9434
  • Logic Elements/Cells: 25000
  • Total RAM: 2002944 bits
  • Temperature Range: 0°C to 85°C
  • Package: 484-BGA
  • Operating Supply Voltage: 1.07 V to 1.13 V
