AZ2225-01L Amazing
Same model may have multiple batches, images only for reference.

AZ2225-01L

Part No AZ2225-01L
Manufacturer Amazing
Catalog TVS - Diodes
Description TVS DEVICE LOW SPEED 1-CH 5V
Datasheet
AZ2225-01L Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Circuit Protection - Transient Voltage Suppressors (TVS) - TVS Diodes
Mfr Amazing
Package Strip
Product Status Active
Type Zener
Bidirectional Channels 1
Voltage - Reverse Standoff (Typ) 5V (Max)
Voltage - Breakdown (Min) 6.1V
Power Line Protection No
Applications General
Temperature Range - Operating -55°C ~ 125°C (TC)
Mounting Type Surface Mount
Package / Case SC-76, SOD-323
Supplier Device Package SOD-323
Standard Package 10 pcs
REACH Status Vendor Undefined
Win Source Part Number 818295-AZ2225-01L
Ultra Librarian 3D Model Ultra Librarian AZ2225-01L CAD Model

Description

The AZ2225-01L is a Zener type transient voltage suppressor (TVS) diode from Amazing.

  • Package: Strip
  • Applications: General
  • Channel: Bidirectional
  • Reverse Standoff Voltage: 5V (max)
  • Breakdown Voltage: 6.1V
  • Mounting Type: Surface mount
  • Temperature Range: -55°C to 125°C
