Products specifications

Manufacturer AMCC
Win Source Part Number 306562-S3015A
Popularity Low
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian S3015A CAD Model

Description

The AMCC S3015A is a T1/E1 single chip short haul/long haul transceiver designed for various telecommunications applications. This integrated circuit provides a comprehensive solution for interfacing with digital transmission lines, handling both T1 and E1 standards. It incorporates functions such as clock recovery, line equalization, and pulse shaping to ensure reliable data transmission and reception over different cable lengths and network conditions.

Applications

  • Digital Cross-Connect Systems (DCS)
  • Channel Banks
  • Private Branch Exchanges (PBX)
  • Voice over IP (VoIP) gateways
  • Wireless Base Stations
  • Digital loop carrier systems

Features

  • Single-chip T1/E1 transceiver
  • Supports both short-haul and long-haul line interfaces
  • Integrated clock recovery with jitter attenuation
  • Line equalization for compensating signal loss
  • Pulse shaping to meet regulatory requirements
  • Diagnostics loopback capabilities
  • Low power consumption
  • Compliance with ITU-T G.703, ANSI T1.403 standards

Benefits

  • Reduced component count, leading to a more compact and cost-effective design
  • Improved system reliability due to integrated functions
  • Simplified board layout and design process
  • Enhanced signal integrity for reliable communication
  • Lower power consumption for energy efficiency
  • Comprehensive diagnostic features to facilitate troubleshooting
  • Compatibility with T1/E1 infrastructure

Technical Specifications

The S3015A generally operates on a 3.3V power supply and offers programmable transmit and receive parameters to optimize performance for varied line conditions. It includes robust clock recovery circuitry, employing a Phase-Locked Loop (PLL) for accurate timing extraction. The device also incorporates extensive built-in self-test (BIST) capabilities for continuous performance monitoring. The physical interface typically involves transformer coupling to the T1/E1 line. It is equipped to handle clock slips and frame alignment challenges and typically comes in a surface-mount package to save board space.
