PT02A-10-6S Real Image
Same model may have multiple batches, images only for reference.

PT02A-10-6S

Part No PT02A-10-6S
Manufacturer Amphenol Industrial Operations
Catalog Circular Connectors
Description CONN RCPT FMALE 6P GOLD SLDR CUP / 6 Position Circular Connector Receptacle, Female Sockets Solder Cup
Datasheet
PT02A-10-6S Datasheet
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Category Connectors, Interconnects>Circular Connectors
Mfr Amphenol Industrial Operations
Series MIL-DTL-26482 Series I, PT
Package Bulk
Connector Type Receptacle, Female Sockets
Number of Positions 6
Shell Size - Insert 10-6
Mounting Type Panel Mount
Mounting Feature Flange
Termination Solder Cup
Fastening Type Bayonet Lock
Orientation N (Normal)
Primary Material Metal
Shell Material Aluminum
Shell Finish Olive Drab Chromate over Cadmium
Contact Finish - Mating Gold
Color Olive Drab
Shielding Unshielded
Temperature Range - Operating -55°C ~ 125°C
Backshell Material, Plating Aluminum, Olive Drab Cadmium
Contact Material Copper Alloy
Insert Material Neoprene
Applications Aerospace, Industrial, Instrumentation, Mass Transit, Military
Base Product Number PT02A
RoHS Status RoHS non-compliant
MSL Level 1 (Unlimited)
REACH Status REACH Affected
ECCN EAR99
HTSUS 8536.69.4020
Other Names 7114621006S,PT02A10-6S-ND,PT02A106S,PT02A10-6S,71-146210-06S,U71-146210-06S
Standard Package 1
Win Source Part Number 1156782-PT02A-10-6S
Ultra Librarian 3D Model Ultra Librarian PT02A-10-6S CAD Model

Description

The PT02A-10-6S is a circular connector from the MIL-DTL-26482 Series I, PT series.

  • Connector Type: It has a receptacle connector type with female sockets and 6 positions.
  • Applications: This connector is designed for use in aerospace, industrial, instrumentation, mass transit, and military applications.
  • Mounting: It has a flange mounting feature and can operate in a temperature range of -55°C to 125°C.
