The Amphenol ICC (FCI) 77313 series is a board-to-board or cable style male pin header connector with a 20 position, 2 row design.

• Manufacturer: Amphenol ICC (FCI)
• Series: 77313
• Style: Board-to-board or cable
• Contact Gender: Male pin
• Positions: 20
• Rows: 2
• Connector Type: Header, Breakaway
• Fastening Type: Push-Pull
• Contact Material: Phosphor Bronze
• Contact Finish (Mating/Post): Tin
• Mounting Type: Through-Hole
• Shrouding: Unshrouded
• Row Spacing: 0.100" (2.54mm)
• Contact Shape: Square
• Contact Length (Mating): 0.413" (10.50mm)
• Contact Length (Post): 0.114" (2.90mm)
• Overall Contact Length: 0.626" (15.90mm)
• Insulation Height: 0.100" (2.54mm)
• Current Rating: 3A per contact
• Operating Temperature: -65°C to 130°C
• Insulation: Thermoplastic
• Flammability Rating: UL94 V-0
• Applications: Board-to-board or cable
