The AD2S1000YSTZ is a state-of-the-art resolver-to-digital converter from the renowned semiconductor manufacturer, Analog Devices Inc. This high-performance chip is designed to provide precise angular displacement and velocity measurements, which are essential in various industrial and automotive applications such as servo motors, robotics, and aerospace systems.

With a 16-bit resolution and a user-selectable velocity output range, the AD2S1000YSTZ offers exceptional accuracy and flexibility. It can process resolver signals with a frequency range of up to 20 kHz, making it suitable for high-speed operations. The device operates over a wide temperature range, ensuring reliability and stability in harsh environments.

The AD2S1000YSTZ integrates an on-chip oscillator and a programmable sinusoidal oscillator that provides excitation for the resolver. It also features fault detection capabilities, including loss of resolver signals, out-of-range input frequency, and system errors, which contribute to the overall safety and robustness of the system it is integrated into.

This converter is available in a compact 48-lead LQFP (Low Profile Quad Flat Package) with the part number YSTZ, signifying the package type and temperature grade. The package is designed to be soldered directly onto a printed circuit board, facilitating easy integration into system designs.

Analog Devices Inc. has a strong reputation for creating high-quality, reliable components, and the AD2S1000YSTZ is no exception. It is a testament to the company's commitment to providing innovative solutions that meet the stringent requirements of modern industrial and automotive systems.

Key Features:

• 16-bit resolution
• User-selectable velocity output range
• Integrated fault detection
• On-chip oscillator
• Programmable sinusoidal oscillator
• 48-lead LQFP package
• Wide operating temperature range

Applications:

• Servo motor control
• Robotics
• Aerospace systems
• Automotive systems
