AD5339ARMZ-REEL7

Part No AD5339ARMZ-REEL7
Manufacturer Analog Devices Inc.
Catalog Data Acquisition - Digital to Analog Converters (DAC)
Description IC DAC 12BIT I2C/SRL 8MSOP
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Analog Devices Inc.
Packaging Reel - TR
Status Active
Number of Bits 12
Number of D/A Converters 2
Settling Time 10μs
Output Type Voltage - Buffered
Differential Output No
Data Interface I2C
Reference Type External
Analog Supply Voltage 2.5 V to 5.5 V
Digital Supply Voltage 2.5 V to 5.5 V
INL/DNL (LSB) ±2, ±0.2
Temperature Range - Operating -40°C to 105°C
Case / Package 8-MSOP
Win Source Part Number 115634-AD5339ARMZ-REEL7
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian AD5339ARMZ-REEL7 CAD Model

Description

Product Overview: AD5339ARMZ-REEL7

The AD5339ARMZ-REEL7 is a high-performance, dual 10-bit digital-to-analog converter (DAC) from Analog Devices Inc., renowned for its precision electronic components. This DAC is designed to offer a compact, efficient solution for converting digital signals into their analog counterparts with high accuracy and stability. The AD5339ARMZ-REEL7 is part of the REEL7 packaging series, which provides components in tape and reel format, suitable for automated assembly processes.

Key Features

  • Resolution: The device boasts a 10-bit resolution, providing fine granularity for analog output signals.
  • Output Range: It offers a flexible reference input, allowing for various output ranges that cater to different application needs.
  • Power Supply: The DAC operates from a single 2.5V to 5.5V power supply, making it versatile for use in both low-power and standard digital systems.
  • Interface: It features a 3-wire serial interface that is compatible with SPI, QSPI™, MICROWIRE™, and DSP interface standards, ensuring easy integration with most microcontrollers and digital systems.
  • Package: The component is available in an 8-lead MSOP (Mini Small Outline Package) that is ideal for space-constrained applications.
  • Temperature Range: It is rated for an industrial temperature range of -40°C to +105°C, making it reliable in harsh operating environments.

Applications

The AD5339ARMZ-REEL7 is a versatile DAC that can be used in a wide array of applications, including:

  • Process control and industrial automation
  • Data acquisition systems
  • Portable battery-powered instruments
  • Digital gain and offset adjustment
  • Automotive systems

With its precision performance and robust packaging, the AD5339ARMZ-REEL7 from Analog Devices Inc. is an excellent choice for designers looking to implement accurate analog signal generation in their digital systems. The device's high integration, coupled with its ease of use, makes it a preferred option for a broad range of applications that require reliable DAC functionality.
