AD8542ARM-RELL

Part No AD8542ARM-RELL
Manufacturer Analog Devices Inc.
Catalog Hard To Find
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Reference Date Code 0017
Reference case TSSOP
Manufacturer Analog Devices Inc.
Manufacturer Homepage www.analog.com
RoHS State Request Verification
Win Source Part Number 717489-AD8542ARM-RELL
Popularity Low
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian AD8542ARM-RELL CAD Model

Description

The AD8542ARM-RELL from Analog Devices Inc. is a high-performance, precision operational amplifier that combines low cost with high accuracy. Ideal for a broad spectrum of applications, this op-amp features rail-to-rail input and output swing, which is coupled with a low input bias current. The device is particularly suitable for battery-powered instruments due to its low power consumption and wide supply voltage range.

Key Features

  • Rail-to-Rail Input/Output: The AD8542ARM-RELL can operate with input and output signals that extend to both supply rails, offering increased dynamic range in single or dual supply operations.
  • Wide Supply Voltage Range: This operational amplifier can function across a wide supply voltage range of 2.7V to 6V, making it versatile for various applications.
  • Low Power Consumption: With a quiescent current of just 45μA per amplifier, this device is optimized for low-power applications, preserving battery life in portable devices.
  • High Accuracy: Precision performance is ensured with a low input offset voltage and low noise, providing accurate signal amplification.
  • Extended Temperature Range: The device is designed to operate over an industrial temperature range of -40°C to +125°C, making it reliable in a variety of harsh environments.

Applications

  • Battery-powered instrumentation
  • Portable medical devices
  • Sensor signal conditioning
  • Data acquisition systems
  • Active filters
  • Audio electronics

The AD8542ARM-RELL is offered in a compact MSOP-8 package, making it an ideal choice for space-constrained applications. Its combination of features ensures that it can provide high-fidelity signal amplification with minimal power loss, making it a top choice for designers looking for a cost-effective yet reliable op-amp solution.

With its robust design and comprehensive feature set, the AD8542ARM-RELL by Analog Devices Inc. stands out as an excellent choice for any application requiring a high-quality, versatile operational amplifier.
