The ADG452BR is a high-performance precision monolithic quad single-pole, single-throw (SPST) switch from Analog Devices Inc., a leader in the semiconductor industry. This switch is designed to provide efficient and reliable performance in a wide range of applications, including data acquisition systems, communication systems, and medical equipment.

Key Features

• Low On Resistance: The ADG452BR boasts a low on resistance typically in the range of 10 ohms, which ensures minimal signal distortion and power loss through the switch, enhancing overall system efficiency.
• Single Supply Operation: Engineered for flexibility, the ADG452BR operates from a single supply voltage ranging from +10 V to +30 V or a dual supply of ±5 V to ±20 V, making it suitable for a variety of power environments.
• Low Power Consumption: With its low power dissipation, the device is ideal for power-sensitive applications, conserving energy without compromising performance.
• Fast Switching Times: The switch features fast transition times (t_ON and t_OFF), providing quick response times that are essential for high-speed signal processing.
• High Off Isolation: The device offers high off isolation, which prevents signal leakage between channels when the switch is in the off position, ensuring signal integrity.

Applications

The versatility of the ADG452BR allows it to be used in a multitude of applications:

• Sample and Hold Circuits
• Test Equipment and Instrumentation
• Analog and Digital Multiplexing
• Battery Powered Systems
• Communication Systems

Quality and Reliability

Analog Devices Inc. is known for its commitment to quality, and the ADG452BR is no exception. It is fabricated on an enhanced LC2MOS process, which provides robust electrostatic discharge (ESD) protection and latch-up immunity. The device is available in a 16-lead plastic DIP (N) package and a 16-lead standard small outline package (R-16). For those seeking improved system performance with a reliable and efficient switch, the ADG452BR is an excellent choice.
