Product Overview: ADG774ABCPZ-R2

The ADG774ABCPZ-R2 is a high-performance, low-voltage, CMOS analog multiplexer from Analog Devices Inc., a leader in the semiconductor industry. This device is part of their extensive range of switch and multiplexer products designed for signal routing in various applications.

Key Features

• Low On-Resistance: The ADG774ABCPZ-R2 features a low on-resistance (<0.5 Ohms typical), which minimizes signal distortion and ensures excellent signal integrity.
• Wide Operating Voltage Range: It operates over a wide supply voltage range of 1.8 V to 3.6 V, making it suitable for battery-powered and portable devices.
• High Throughput: With a 3 dB bandwidth of over 500 MHz, this multiplexer can handle high-speed signals without significant attenuation, making it ideal for video and data applications.
• Low Crosstalk: The device exhibits low crosstalk between channels, which is critical in applications where signal isolation is required.
• Lead-Free and RoHS Compliant: The ADG774ABCPZ-R2 is available in a lead-free, 20-lead LFCSP package and is RoHS compliant, adhering to environmental standards.

Applications

The versatility of the ADG774ABCPZ-R2 allows it to be used in a variety of applications, including:

• Data acquisition systems
• Communication systems
• Audio and video switching
• Automatic test equipment
• Relay replacement

Product Specifications

The ADG774ABCPZ-R2 boasts an array of technical specifications that make it a reliable choice for designers:

• Channels: 4-channel, 2:1 multiplexer
• Switching Times: t_ON of 16 ns and t_OFF of 4 ns
• ESD Protection: Enhanced ESD (Electrostatic Discharge) protection up to 2 kV
• Package: 20-lead LFCSP (Lead Frame Chip Scale Package)
• Temperature Range: Operates over the extended industrial temperature range of -40°C to +85°C

Ordering Information

The ADG774ABCPZ-R2 is available for order and can be sourced through Analog Devices' distribution network. For detailed ordering and product information, please refer to the Analog Devices official website or contact their customer support for assistance.

With its robust feature set and high-performance capabilities, the ADG774ABCPZ-R2 is an excellent choice for designers looking for a reliable multiplexer solution.
