The ADM660ARZ is a versatile charge pump voltage converter from Analog Devices Inc., a leader in high-performance semiconductors. This integrated circuit is designed to provide a simple, efficient, and compact solution for converting voltage levels in a wide range of electronic applications.

Key Features

• Flexible Voltage Conversion: The ADM660ARZ can be configured for voltage inversion, doubling, or splitting, making it suitable for various design requirements.
• High Efficiency: With a typical efficiency of 98%, this charge pump minimizes power loss and is ideal for battery-powered devices.
• Low Power Consumption: The quiescent current is only 100 µA, which helps to prolong battery life in portable applications.
• Wide Voltage Range: It operates over a wide input voltage range from 1.5V to 12V, accommodating a broad spectrum of power sources.
• High Output Current: Capable of delivering up to 100mA of output current, it can power a variety of low-power circuits and components.

Applications

The ADM660ARZ is suitable for a multitude of applications including:

• Battery-operated equipment
• Portable computers
• Medical instruments
• Operational amplifier power supplies
• Handheld instrumentation
• Telecommunications infrastructure

Product Specifications

The ADM660ARZ comes in a compact SOIC-8 package and features a shutdown function that reduces the supply current to 0.01 µA, further conserving energy when the device is not in active use. It also includes thermal overload protection to ensure reliable operation under varying conditions.

Conclusion

With its exceptional efficiency, low power consumption, and versatile voltage conversion capabilities, the ADM660ARZ from Analog Devices Inc. is an excellent choice for designers looking to add flexible power management to their electronic projects. Its robust feature set and ease of use make it a go-to component in the realm of charge pump voltage converters.
