Analog Devices Inc. LTC2956IUD-2#PBF Overview

The LTC2956IUD-2#PBF is a sophisticated power control management IC from Analog Devices Inc., designed to enhance system control and extend battery life in portable and handheld devices. This component is part of the LTC2956 series, which offers a range of features to manage the power-up and power-down sequences of electronic systems with precision and reliability.

Key Features

• Wide Operating Voltage Range: The device supports an input voltage range from 2.7V to 26.4V, making it versatile for various applications across different voltage requirements.
• Low Quiescent Current: With an ultra-low quiescent current of only 20uA (typical) when in standby mode, it helps conserve energy, making it ideal for battery-powered applications.
• Adjustable Turn-On and Turn-Off Thresholds: The LTC2956IUD-2#PBF allows for precise control over system power states with programmable thresholds.
• Pushbutton Control: This IC integrates pushbutton input control, providing an easy and intuitive interface for the end-user to power the system on and off.
• Configurable Timer Delays: It features adjustable timer settings for turn-on and turn-off delays, offering flexibility in power sequence timing to match specific system requirements.
• Temperature Range: The industrial temperature range from -40°C to 85°C ensures reliable operation under varying environmental conditions.

Applications

The LTC2956IUD-2#PBF is suitable for a wide array of applications where efficient power management is crucial. These include:

• Portable and battery-powered equipment
• Handheld medical devices
• Remote monitoring systems
• Industrial control systems
• Automotive electronics

Package and Quality

The LTC2956IUD-2#PBF is offered in a compact, 20-lead (3mm × 3mm) QFN package, ensuring a minimal footprint on the PCB. Its robust design conforms to the high-quality standards set by Analog Devices Inc., making it a reliable choice for mission-critical applications where consistent performance is non-negotiable.

With its comprehensive feature set and flexible configuration options, the LTC2956IUD-2#PBF from Analog Devices Inc. stands out as a powerful solution for advanced power management in modern electronic systems.
