The Maxim Integrated MAX320EUA is a precision, dual-channel analog switch designed to provide high-performance switching capabilities in a wide range of applications. This compact and efficient switch is part of Maxim's commitment to delivering high-quality analog integration, and it is ideal for systems where space is at a premium and low power consumption is essential.

The MAX320EUA offers a unique combination of low on-resistance and low supply current, making it an excellent choice for battery-powered devices. With a typical on-resistance of just 35 ohms, it ensures minimal signal distortion and loss, which is critical for maintaining signal integrity in sensitive analog circuits. The device operates from a single +2V to +12V supply or from dual ±2V to ±6V supplies, providing versatility in different circuit configurations.

This analog switch is designed with break-before-make switching action, which prevents momentary shorting when switching channels. This feature is particularly important in applications such as audio signal routing, where it helps to avoid pops or clicks that can occur during channel transitions. The MAX320EUA also boasts fast switching times, typically 150ns for turn-on and 100ns for turn-off, ensuring swift and responsive operation in time-sensitive applications.

The MAX320EUA comes in a compact 8-pin µMAX package, which is highly space-efficient and suitable for high-density PCB layouts. Its small footprint makes it an excellent choice for portable devices, such as handheld audio players, medical instruments, and communication devices, where space and power efficiency are critical design considerations.

In summary, the Maxim Integrated MAX320EUA analog switch combines low on-resistance, low power consumption, fast switching speeds, and a small package size. It is a reliable and versatile component that can be used in a variety of applications, from signal routing to data acquisition systems, where precise and efficient analog switching is required.

Key Features:

• Low On-Resistance: 35 ohms typical
• Single or Dual Supply Operation: +2V to +12V or ±2V to ±6V
• Fast Switching Times: 150ns turn-on, 100ns turn-off
• Break-Before-Make Switching Action
• Compact 8-pin µMAX Package
